Nodweddion

●Fully compatible with ITU-T G.984.1/2/3/4

●Support downlink rate 2.448Gbit/s, uplink rate is 1.244Gbit yr eiliad

●Support 32 TCONT, 256 GEMPORT

●Support bidirectional FEC, supports the RS (255, 239) FEC decoding

●Support AES128 encryption and decryption functions with G.984 standard

●Support DBA bandwidth allocation

●Support three layer routing functions

●Support PLOAM, embedded OMCI management with G.984 standard

●Support Dying-Gas detection and reporting

●Support rogue ONU detection

●Support GPONarbed ynni o brotocol G987.3

●Support Tag/Untag Ethernet frame of 802.1 and Q 802.3 standard, support QinQ

●Support for flexible flow classification, maximum 520 flow classification rules

●Support link error monitoring and loop monitoring

●Support a variety of multicast forwarding mode, support multicast replication

●Auto-negotiation and manual settings of Ethernet supporting rate, duplex mode

●UNI interface supports STP/RSTP protocol

●Provide QoS guarantees for different priority business through SLA restraining, Policing, queue management scheduling / congestion avoidance, discarding management mode

●Support flow control based on entrance , choose Pause frame reaction pressure to Packet loss for the business beyond

●Support HQoS function

Manyleb

Eitem dechnegol	1GE GPON ONU
Chipset	ZTE
Rhyngwyneb PON	1 porthladd GPON (PX20 a mwy) Tonfedd:Tx1310nm, Rx 1490nm Cysylltydd SC / UPC Receiving saturation: Greater than or equal to -8dBm Receiving sensitivity: Less than or equal to -30dBm Trosglwyddo pŵer optegol: 0 plws 4dBm Pellter trosglwyddo: 20KM
rhyngwyneb LAN	110/100/1000M Llawn / Hanner, cysylltydd RJ45
Cyflwr gweithredu	Temperature: -30 degree - plus 70 degree Humidity: 10 percent -90 percent （non-condensing）
Cyflwr storio	Temperature : -30 degree - plus 70 degree Humidity :10 percent -90 percent （non-condensing）
Cyflenwad pŵer	DC 12V/0.5A
Power consumption	Llai na neu'n hafal i 4W
Dimensiwn	110mm(L) x100mm(W) x23mm (H)
Pwysau net	0.2

Paramedrau Meddalwedd

Eitem Dechnegol
Syml	Cefnogi Pont a Llwybro DHCP/PPPOE/IP Statig Cefnogi llwybr Statig Support NATSupport MPCP discoverister Support authentication Mac/Loid/Mac plus Loid Support Triple Churning Support DBA bandwidth Support auto-detecting, auto-configuration, and auto firmware upgrade Support authentication SN/Psw/Loid/Loid plus Psw
Larwm	Support Dying Gasp Support Port Loop Detect Support Eth Port Los
LAN	Cefnogi cyfyngu cyfradd Porthladd Support Loop detection Cymorth rheoli llif Cefnogi rheoli Storm
VLAN	Cefnogi modd tag VLAN Cefnogi modd tryloyw VLAN Cefnogi modd boncyff VLAN (uchafswm o 8 vlan) Cefnogi modd cyfieithu VLAN 1:1 (uchafswm o 8 vlan) Auto VLAN detection
Amlddarllediad	Cefnogi IGMPv1/v2 Support IGMP Snooping Max Multicast vlan 8 Grŵp Multicast Uchaf 64
QoS	Cefnogi 4 ciw Cefnogi SP a WRR Cefnogaeth 802.1P
Rheolaeth	Support CTC OAM 2.0 and 2.1 Support ITUT984.x OMCI Support WEB Support TELNET Support CLI
Trwybwn	Upstream >900Mbps Downstream >960Mbps
Paquete perdido	14Awr /Ar Goll 0

Adeiladu Rhwydwaith

GPON 1GE ONT RTL Chipset 2

Gwybodaeth archebu

Enw Cynnyrch	Model Cynnyrch	Disgrifiadau
GPON ONT	1GE GPON ONT	Rhyngwyneb Ethernet 1GE, rhyngwyneb 1 GPON, casin plastig, addasydd cyflenwad pŵer allanol
